| Bore × Stroke (mm) | 77mm x 80mm |
| Carburation | PGM FI electronic fuel injection |
| Compression Ratio | 10.7 : 1 |
| Engine Displacement (cc) | 745cc |
| Engine Type | Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder |
| Max. Power Output | 43.1kW/6,750rpm(35kW/6,000rpm) |
| Max. Torque | 69Nm/4,750rpm(65/4,000rpm) |
| Starter | Electric |
| Throttle Bore | |
| C02 Emissions (g/km) | 85g |
| Oil Capacity (Litres) | 4.0L |
| ABS System | |
| Brakes Front | 296mm double hydraulic disc with radial 4-piston caliper |
| Brakes Rear | 240mm single hydraulic disc with 1-piston caliper |
| Suspension Front | 41mm USD,153.5mm stroke |
| Suspension Rear | Monoshock damper, Pro-Link swingarm, 150mm travel |
| Tyres Front | |
| Tyres Rear | |
| Tyre Size Front | 120/70-R17M/C (58H) |
| Tyre Size Rear | 160/60-R15M/C (67H) |
| Wheels Front | Spoke Wheel 17M/C x MT3.50 |
| Wheels Rear | Spoke Wheel 15M/C x MT4.50 |
| Battery Capacity (VAh) | 12V/11AH |
| Caster Angle | 27° |
| Dimensions (L×W×H) (mm) | 2215m x 940mm x 1370mm |
| Frame type | Diamond; steel pipe |
| Fuel Tank Capacity (Litres) | 13.2L |
| Fuel Consumption | 3.6L/100km |
| Ground Clearance (mm) | 165mm |
| Kerb Weight (kg) | 236kg |
| Seat Height (mm) | 820mm |
| Trail (mm) | 104mm |
| Wheelbase (mm) | 1590mm |
| Clutch | Wet multiplate hydraulic 2-clutch |
| Final Drive | Chain |
| Transmission Type | 6-speed dual clutch transmission |
| Headlights | LED DRL |
| Instruments | 5inch color TFT Meter Choose from 4 type design Various functions can be selected and displayed Can be operated by the switch on handle. |
| Tail Light | LED |
| Connectivity | Yes |
| USB Socket | Type-C |
| Self Cancelling Indicators | Yes |
| Security | Smart system |
